SGS TUV Hard Chrome Piston Rod , Chrome Plated Round Bar NSS 300 500 800 Hours 45# 42CrMo

SGS TUV Hard Chrome Piston Rod , Chrome Plated Round Bar NSS 300 500 800 Hours 45# 42CrMo

    • SGS TUV Hard Chrome Piston Rod , Chrome Plated Round Bar NSS 300 500 800 Hours 45# 42CrMo
    • SGS TUV Hard Chrome Piston Rod , Chrome Plated Round Bar NSS 300 500 800 Hours 45# 42CrMo
  • SGS TUV Hard Chrome Piston Rod , Chrome Plated Round Bar NSS 300 500 800 Hours 45# 42CrMo

    Product Details:

    Place of Origin: CHINA
    Brand Name: DALLAST
    Certification: SGS TUV
    Model Number: Model

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Packaging Details: Wooden box
    Delivery Time: 15-25DAYS
    Supply Ability: 100000PCS/YEAR
    Contact Now
    Detailed Product Description
    Material: 45# 42CrMo Color: Black
    NSS: Endure 300;500;800hours Type: Hollow/Solid Rod
    Application Environment: At Sea Or In Harsh Environments Surface Hardness: >HV850

    45# 42CrMo Piston Hollow Rods Hard Chrome Plated Steel Bar NSS 800 Hours


    Material :45# 42CrMo



    Color :Black



    NSS:Endure 300;500;800hours



    Type:Hollow/Solid Rod


    Application Environment:At sea or in harsh environments Surface hardness:>HV860



    SURFACE ROUGHNESS:Ra≤0.2 micron and Rt≤2 micro



    TOLERANCES ON DIA:ISO f10 on the diameter



    LENGTH:MAX 5 meter



    Testing Standing une-en iso9227:2017



    · Sal solution: 50 (+/- 5) g/l of NaCl. Water is demineralized and salt purity is 99.5%.

    · Environmental temperature: 35 °C.

    · pH of salt solution is 6.8.

    · Volumen of salt solution is 38.4 ml/day.

    · Density of salt solution is 1,030 g/cm3.

    · Spraying is 1.5 (+/- 0.5) ml/h.

    Test Result :NSS can endure 300 hours ;500 hours; 800 hours





    In the whole crafts process, there are 2 times remove hardening forces: the first remove hardening force in the heat treatment process, hardening force remove is about 80%; the second remove hardening force in the surface treatment process, hardening force remove is about 90%-95%. Therefore, the piston rod is not easily deformed during use or transportation.



    CHEMICAL COMPOSITION



    Material C% Mn% Si% S% P% V% Cr%
    Ck45 0.42-0.50 0.50-0.80 0.04 0.035 0.035
    ST52 0.22 1.6 0.55 0.035 0.04
    20MnV6 0.16-0.22 1.30-1.70 0.10-0.50 0.035 0.035 0.10-0.20
    42CrMo4 0.38-0.45 0.60-0.90 0.15-0.40 0.03 0.03   0.90-1.20
    40Cr 0.37-0.45 0.50-0.80 0.17-0.37       0.80-1.10



    MECHANCIAL PROPERTIES



    Material T.S N/MM2 Y.S N/MM2 E%(MIN) CHARPY CONDITION
    CK45 610 355 15 >41J NORMALIZE
    CK45 800 630 20 >41J Q + T
    ST52 500 355 22   NORMALIZE
    20MnV6 750 590 12 >40J NORMALIZE
    42CrMo4 980 850 14 >47J Q + T
    40Cr 1000 800 10   Q + T
