8 Inch Bore Telescoping Dump Truck Hydraulic Cylinder , 3 Stage Hydraulic Cylinder

8 Inch Bore Telescoping Dump Truck Hydraulic Cylinder , 3 Stage Hydraulic Cylinder

    • 8 Inch Bore Telescoping Dump Truck Hydraulic Cylinder , 3 Stage Hydraulic Cylinder
    • 8 Inch Bore Telescoping Dump Truck Hydraulic Cylinder , 3 Stage Hydraulic Cylinder
    • 8 Inch Bore Telescoping Dump Truck Hydraulic Cylinder , 3 Stage Hydraulic Cylinder
  • 8 Inch Bore Telescoping Dump Truck Hydraulic Cylinder , 3 Stage Hydraulic Cylinder

    Product Details:

    Place of Origin: Shandong China
    Brand Name: Dallast
    Certification: GS CE ISO9001
    Model Number: Customized

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: negotation
    Packaging Details: Carton or According to Customer's Require
    Delivery Time: 15-25 days
    Payment Terms: T/T, Western Union, D/A, D/P, L/C
    Supply Ability: 50000 Pieces/Per year
    Contact Now
    Detailed Product Description
    Body Material: 45# Seamless Steel Pipe/27SiM Brand Name: DALLAST
    Hydraulic System: Multi Stage Supply Condition: Ground And Chrome Plated
    Seals: PARKER Quality: Perfect Quality Control
    Adjusted Form: Regulated Type Operating Pressure: 3000 Psi

    8 Inch Bore Telescoping Dump Truck 3 Stage Large Hydraulic Cylinder



    MODEL NO. Stage First Stage Diameter Stroke Largest Sleeve OD Closed length Mounting distance
    FC-3-107-2855 3 107mm 2855mm 152mm 1268mm 311mm
    FC-3-107-3115 3 107mm 3115mm 152mm 1368mm 311mm
    FC-3-107-3265 3 107mm 3265mm 152mm 1418mm 311mm
    FC-3-107-3415 3 107mm 3415mm 152mm 1468mm 311mm
    FC-3-107-3715 3 107mm 3715mm 152mm 1568mm 311mm
    FC-3-126-3230 3 126mm 3230mm 219mm 1403mm 343mm
    FC-3-126-3680 3 126mm 3680mm 219mm 1553mm 343mm
    FC-3-126-3830 3 126mm 3830mm 219mm 1603mm 343mm
    FC-3-126-4400 3 126mm 4400mm 219mm 1803mm 343mm
    FC-4-126-4145 4 126mm 4145mm 219mm 1357mm 343mm
    FC-4-126-4345 4 126mm 4345mm 219mm 1407mm 343mm
    FC-4-126-4545 4 126mm 4545mm 219mm 1457mm 343mm
    FC-4-126-4745 4 126mm 4745mm 219mm 1507mm 343mm
    FC-4-126-4945 4 126mm 4945mm 219mm 1557mm 343mm
    FC-4-126-5145 4 126mm 5145mm 219mm 1607mm 343mm
    FC-4-145-4110 4 145mm 4110mm 219mm 1357mm 343mm



    There are many manufacturers of telescopic hydraulic cylinders to choose from and many offer custom design options to suit specific applications. Double acting cylinders as well as single acting cylinders are also an option when it comes to these cylinders. Double acting cylinders are extended and retracted by use hydraulic pressure in both directions. Some even use a combination of both single and double acting technology, where the piston is double acting and the rest of the stages are single acting. Telescopic cylinders are often used in and considered in regards to heavy machinery, but there are smaller bore designs used in lighter applications as well. There are a range of specific designs, features, and capabilities that can be considered and employed when it comes to telescopic hydraulic cylinders.



    Cylinder Advantages:

    1. Main export market:USA, Canada, South Korea, Russia, Australia, Indonesia, Malaysia, Fiji Island, Kenya, Philippines, Bolivia, the United Arab Unites,Singapore

    2. Material:Alloy steel,Carbon steel,Stainless steel,27SiMn

    3. Seal:Kaden,Hallite, Parker,NOK,SKF etc

    4. Rod :Chrome plated and quenched.Has good mechanical properties, long service life

    5. Cylinder:Honing machining /boring /rolling

    6. Hydraulic Cylinders Certification ISO9001:2009, SGS, TS16949, RoHS, CNAS Certification

    7. Experience in export North America, Australia, Asia, Middle East, Africa

    8. We are professional manufacturer and supplier in hydraulic cylinder.

    9. We do accept OEM manufacturing. We will provide competitive price and make the exact cylinder according to your specification and drawing.

    10. We have professional R&D team with rich design experience.

    11. We also establish strict but scientific product testing system so that products have perfect performance.

    12. One year warranty and long time track service is offered to solve any problems you meet after sale.





    FQA:

    1. How can i get a booklet and buy a cylinder from you?

    A: Extremely easy! Just leave me a message or email or call me directly, let me know you are interesting in our products. I will talk with you for the details soon!



    2. Can you tell me the price for the cylinder?

    A: 1. Please advise the drawing with technical requirement.

    2. Please advise the model No. after you check our booklet.

    3. Please advise the tipping capacity, number of stages, closed length, mounting type and size.

    4. Please also help advice the quantities, this is especially important.



    3. Do your products come with a warranty?

    A: Yes, we have one year warranty. In this year, if the quality problem we will free repair for you.



    4. Hydraulic cylinder internal leakage?

    A: 3 main reasons causing internal leakage: Overload, polishing bad controlled, cheap seal kits. As is known to all, vehicles in China are often overloaded, our products all designed to bear the overload power. Advanced equipment could assure the polish processing. And we use the imported/TOP brand seals to meet customers' requirement.
