Single Acting FC Chrome Hydraulic Oil Cylinder for Agricultural Farm Truck

Single Acting FC Chrome Hydraulic Oil Cylinder for Agricultural Farm Truck

    • Single Acting FC Chrome Hydraulic Oil Cylinder for Agricultural Farm Truck
    • Single Acting FC Chrome Hydraulic Oil Cylinder for Agricultural Farm Truck
    • Single Acting FC Chrome Hydraulic Oil Cylinder for Agricultural Farm Truck
  • Single Acting FC Chrome Hydraulic Oil Cylinder for Agricultural Farm Truck

    Product Details:

    Place of Origin: Shandong
    Brand Name: Dallast
    Certification: Gs, RoHS, Ce, ISO9001
    Model Number: Customized

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Piece
    Price: Negotiation
    Packaging Details: Plywood Box or Pallet
    Delivery Time: 15-25 Days
    Payment Terms: T/T, Western Union, D/P, L/C
    Supply Ability: 50,000 Pieces/Year
    Contact Now
    Detailed Product Description
    Hardness: HRC 45-55 Seals: Parker, Merkel, Hallite
    HS Code: 8412210000 Power: Hydraulic
    Origin: Shandong, China Delivery Time: 15-25 Days
    Work Temperature: Normal Temperature Specification: Customized
    High Light:

    dump truck telescopic cylinder

    ,

    dump trailer hydraulic cylinder

    Single Acting FC Chrome Hydraulic Oil Cylinder for Agricultural Dump Truck / Farm Truck

    Main Parameters:
    Single-acting Hydraulic Cylinder Details:
    This is for single-acting application, and with heavy duty welded construction. Cylinder’s standard color is black, orange or as per requirement. In addition, all seals are manufactured to US specification, and being 100% hydro-pressure tested before delivery. Rod surface treatment is for chrome plated or as per requirement. Hydraulic cylinder’s standard is B type piston (optional: A type piston).

    ModelExtended
    Stages
    Working PressureMax. stageMax. strokeLifting
    Capacity
    Suitable Length of Truck Body
      (MPa)Diameter(mm)(mm)(ton)(m)
    129-3E-3880316-19129388020-355.2
    149-3E-3880316-19149388025-455.2
    149-3E-4280316-19149428025-455.6
    149-4E-3880416-19149388025-405.2
    149-4E-4280416-19149428025-405.6
    169-4E-4280416-19169428030-505.2-5.6
    169-4E-4640416-19169464032-555.6-6.1
    169-4E-5000416-19169500032-606.2-6.8
    169-4E-5180416-19169518032-606.2-6.9
    169-4E-5390416-19169539032-606.2-6.9
    169-4E-5460416-19169546032-606.5-7.3
    185-4E-4280416-19185428025-455.6
    185-4E-4640416-19185464030-455.6-6.1
    This product is used in numerous application including:
    1. Dump truck.
    2. Pump trucks.
    3. Truck mounted crane.
    4. sanitation truck Earth moving equipment, Drilling Rigs, Road and Construction equipments, Cranes, Material handling equipments, Mining Equipments, Plastic Mould Machine, Cement Factories, Special Purpose Cylinders.
    The above data for reference only, we can fully meet your requirements to make customers satisfied with the product. If you need, feel free to contact us and we can advice and design.


    FAQ:
    1. How can I decide which model to buy?
    We will recommend the most suitable machines for you after informed by your requirements.
    2. OME Service Available?
    (1) Usually, we will manufacture the products as our design.
    (2) We also can make any products according to clients’ requirements.
    3. Do your products come with a warranty?
    Yes, we have one year warranty. In this year, if the quality have problems we will free repair for you.
    4. Delivery Time?
    (1) For standard specification products, usually 15-25 days.
    (2) For non-standard products, usually more than 1 month.
    5. How about the warranty and after-sale service?
    All of our products have one year warranty, and we can offer you long-distance after-sale
    service 7/24h.

    6. Can we design our own package or print our own logo?
    Yes! Package and logo will be made according to your requirements.

    Product Description:

    Hydraulic cylinders are an important industrial tool used in machinery, manufacturing, and a number of other functions. The basic design of a hydraulic cylinder has changed little over the years. Hydraulic cylinders have enormous push/pull power and can haul, dig, push, drill, and move heavy objects and materials. The work by exploiting the mechanics of pressure exerted on the piston. The force is equal to the surface area multiplied by pounds per square inch of pressure.

    Sealing system
    All the hydraulic cylinders produced by our company adopt the seal ring products of Parker, Merkel.

    Piston rod
    The piston rod is made of high strength carbon steel with precision grinding treatment. With the design concept of improving the rod strength and the high performance heat treatment, hard chrome plating and CNC tumbling, the even veins and high degree of finish of the surface is guaranteed, and it has good oil membrane at the surface, which improves the service life of the seal parts.

    Guide sleeve
    The sleeve is made of high strength spheroidal graphite cast iron and high strength steel under buffering inner bore copper welding treatment.

    Piston and piston seals
    The standard piston is of one-piece steel structure. The firm lock-up between the long screw thread and the steel ball is convenient for the installation and it also guarantees the reliable operation under high speed load. New design of screwing parts greatly improved the cross section where the piston rod bears the axial load and improves the strength of piston rod to the maximum.

    Custom hydraulic cylinder (OEM).
    Not only we could manufacture all kinds of heavy duty hydraulic cylinder construction and mining
    trucks according to the drawing from customers,but also we could make a design according to
    customers’requirements . If you require our engineer to make a design , please advise us the
    following specification :
    1. Rated pressure
    2. Working pressure
    3. Test pressure
    4. Working condition and environment ,for example ,temperature ,working frequency
    5. Pulling force ,and return stroke force
    6. Pulling and return speed
    7. Assembly size
    8. Seal ring requirements .For example , brand ,seal material etc .
    9. Tube and piston rod raw material requirements

    Company Profiles:

    Dallast Technology Co., Ltd is one of the largest and most professional hydraulic cylinder manufacturer in China. We own an over 90,000 square meters modern standard factory, and more than 220 sets of state-of-the-art large digital equipments, ball rolling machines, honing machines, CNC, Boring machine, lathe, cutting machine, welding machine, auto welding robot, sand blast, painting etc.
