Home ProductsHydraulic Hoist Cylinder

Hydraulic Hoist Cylinder Heavy Duty High Pressure Ships Dam Gates

Hydraulic Hoist Cylinder Heavy Duty High Pressure Ships Dam Gates

    • Hydraulic Hoist Cylinder Heavy Duty High Pressure Ships Dam Gates
    • Hydraulic Hoist Cylinder Heavy Duty High Pressure Ships Dam Gates
    • Hydraulic Hoist Cylinder Heavy Duty High Pressure Ships Dam Gates
    • Hydraulic Hoist Cylinder Heavy Duty High Pressure Ships Dam Gates
  • Hydraulic Hoist Cylinder Heavy Duty High Pressure Ships Dam Gates

    Product Details:

    Place of Origin: shangdong
    Brand Name: DALLAST
    Certification: ISO9001-2009 ,TS16949
    Model Number: Customized

    Payment & Shipping Terms:

    Minimum Order Quantity: 1PCS
    Price: Negotiable
    Packaging Details: shrink film, pallet, plywood case and carton
    Delivery Time: 20- 25 days after down payment
    Payment Terms: T/T, L/C, Western Union,Paypal
    Supply Ability: 3000PCS per year
    Contact Now
    Detailed Product Description
    Standard: Nonstandard Type: Double Acting
    Temperature: -30ºC~150ºC Usage: Heavy Duty Hydropower Station, Dame Gates
    Color: Any Color You Want Material: Steel
    High Light:

    dump truck hoist cylinder

    ,

    hydraulic lift cylinder

    Heavy Duty High Pressure Ships Dam Gates Hydraulic Hoist Cylinder



    Products Discription:

    Gland High grade ductile iron
    Tube

    Cold drawn honed tubling

    Piston High grade ductile iron
    Piston rod Chromed C45
    Piston seal Urethane seal
    End cap Casting seel
    Mounting style Pins and clips included
    Gland seals Polyurethane U-cup
    Rod wiper Urethane snap in
    Paint color Semi-gloss black, grey, red



    The company mainly products



    1. Engineering hydraulic cylinder series:

    Hydraulic cylinder mainly refers to: hydraulic cylinders for hydraulic systems such as construction machinery, heavy machinery, cranes and mining machinery, but not limited to the above. Hydraulic cylinder for the double-acting, single-piston hydraulic cylinder, the installation of more use of earrings, according to the cylinder head and cylinder connection can be divided into different ways of external thread connection, the card key connection and flange connection.

    2. Metallurgical equipment hydraulic cylinder


    Metallurgical equipment standard hydraulic cylinder with a variety of specifications and varieties, bore diameter is generally in the 40-320mm range, working pressure ≤ 16MPa, available hydraulic oil mechanical system loss of oil and emulsion and other working medium, the use of temperature range of -40 ~ 80 ℃ , The installation of a flange, earrings, pins and other forms and in line with ISO6020 / 1-1981 standards, in addition to tripod (base) type.

    3. Vehicles hydraulic cylinder

    This series of hydraulic cylinders is mainly used in hydraulic systems of construction machinery, lifting and transport machinery, mining equipment and other vehicles, the installation method is: earrings, are double-acting single-piston hydraulic cylinder.

    4. Heavy duty hydraulic cylinder

    CD / CG250 CD / CG350 series heavy duty hydraulic cylinder
    Heavy-duty hydraulic cylinder has a single-piston double-acting CD-type differential piston cylinder and double acting CG-type double-acting piston cylinder two. Its installation form and size in line with ISO3320 standards, especially suitable for harsh environments, heavy working conditions, suitable for steel, casting and machinery manufacturing and other occasions.


    5. Telescopic sleeve hydraulic cylinder

    TG series of single-acting multi-stage telescopic sleeve hydraulic cylinder, with small size, large stroke, etc., can be used for heavy vehicles, agricultural vehicles and other vehicles tilting the bucket lift cylinder.

    Hydraulic Hoist Cylinder Heavy Duty High Pressure Ships Dam Gates

    Hydraulic Hoist Cylinder Heavy Duty High Pressure Ships Dam Gates

    Hydraulic Hoist Cylinder Heavy Duty High Pressure Ships Dam Gates
