Hard Chrome Plated Rod Piston Hydraulic Cylinder Parts For Single Acting Truck

Hard Chrome Plated Rod Piston Hydraulic Cylinder Parts For Single Acting Truck

    • Hard Chrome Plated Rod Piston Hydraulic Cylinder Parts For Single Acting Truck
    • Hard Chrome Plated Rod Piston Hydraulic Cylinder Parts For Single Acting Truck
    • Hard Chrome Plated Rod Piston Hydraulic Cylinder Parts For Single Acting Truck
  • Hard Chrome Plated Rod Piston Hydraulic Cylinder Parts For Single Acting Truck

    Product Details:

    Place of Origin: Shandong
    Brand Name: DALLAST
    Certification: Gs, RoHS, Ce, ISO9001
    Model Number: Customized

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Piece
    Price: Negotiation
    Packaging Details: Plywood Box or Pallet
    Delivery Time: 15-25 Days
    Payment Terms: T/T, Western Union, D/P, L/C
    Supply Ability: 50,000 Pieces/Year
    Contact Now
    Detailed Product Description
    Working Method: Straight Trip Delivery Time: 15-25 Days
    Structure: Piston Cylinder Or Telescopic Cylinder Specification: Customized
    Material: 20#, 45# Steel, 21#, 27# SiMn Honed Tube: 20-2000 Mm, Heat Treatment
    Warranty: One Year Hardness: HRC 45-55

    Hard Chrome Plated Piston Hydraulic Cylinder Parts for Double Acting Truck



    pipe bar for hydraulic cylinder



    Detailed Product Description



    1. Material: CK45

    2. Ground and chrome plated

    3. Diameter: 6~1000mm

    4. length: 1000~8000mm

    5. ISO9001: 2008



    Detailed Description



    1. CHEMICAL COMPOSITION

    Material C% Mn% Si% S% P% V% Cr%
    Ck45 0.42-0.50 0.50-0.80 0.04 0.035 0.035
    ST52 0.22 1.6 0.55 0.035 0.04
    20MnV6 0.16-0.22 1.30-1.70 0.10-0.50 0.035 0.035 0.10-0.20
    42CrMo4 0.38-0.45 0.60-0.90 0.15-0.40 0.03 0.03   0.90-1.20
    40Cr 0.37-0.45 0.50-0.80 0.17-0.37       0.80-1.10



    2. MECHANCIAL PROPERTIES

    Material T.S N/MM2 Y.S N/MM2 E%(MIN) CHARPY CONDITION
    CK45 610 355 15 >41J NORMALIZE
    CK45 800 630 20 >41J Q + T
    ST52 500 355 22   NORMALIZE
    20MnV6 750 590 12 >40J NORMALIZE
    42CrMo4 980 850 14 >47J Q + T
    40Cr 1000 800 10   Q + T



    3. SUPPLY CONDITION

    Ground and chrome plated



    4. CHROME THICKNESS

    20 to 30 micron



    5. SURFACE ROUGHNESS

    Ra≤0.2 micron and Rt≤2 micro



    6. TOLERANCES ON DIA

    ISO f7 on the diameter



    7.OVALITY

    Half of the tolerance ISO f7



    8. STRAIGHTNESS

    ≤0.2MM/M



    9. SURFACE HARDNESS

    850-1150HV (vickers 100g)



    10. COHESION

    No cracks,breaking or detaching after thermic shock(warming up at 300 celsius degrees and cooling

    in water)



    FAQ :



    Questions: Answers:
    Q1. You are a trading company or manufacturer? We are a manufacturer, major in hydraulic cylinders for 15 years OEM.
    Q2. Can I order samples for testing? Of course, our quality will satisfy you.
    Q3. Can you accept OEM or ODM? Of course, any kind and color can be provided according to your requirements.
    Q4. Have you ever exported to foreign countries? We have exported hydraulic cylinders to Russia, Romania, Morocco, Thailand, Germany and so on.



    Company Profile :



    Dallast Technology Co., Ltd is a leading professional manufacturer of hydraulic cylinder more than 15 years, we are specializing in developing, designing, manufacturing, sales and after sales service of hydraulic cylinder, not only the standard but also OEM products. In order to provide better products to our customers, we make a huge investment to introduce our advanced hydraulic technology at home and abroad, such as CNC machine, automatic cylinder welding equipment, cylinder turning center, plasma cutting machine etc.



    Product Show :



    Hard Chrome Plated Rod Piston Hydraulic Cylinder Parts For Single Acting Truck
