Double Acting Flange High Pressure Hydraulic Cylinder High Tonnage

Double Acting Flange High Pressure Hydraulic Cylinder High Tonnage

    • Double Acting Flange High Pressure Hydraulic Cylinder High Tonnage
    • Double Acting Flange High Pressure Hydraulic Cylinder High Tonnage
    • Double Acting Flange High Pressure Hydraulic Cylinder High Tonnage
    • Double Acting Flange High Pressure Hydraulic Cylinder High Tonnage
  • Double Acting Flange High Pressure Hydraulic Cylinder High Tonnage

    Product Details:

    Place of Origin: Shandong China
    Brand Name: Dallast
    Certification: GS CE ISO9001
    Model Number: Customized

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: negotation
    Packaging Details: Carton or According to Customer's Require
    Delivery Time: 15-25 days
    Payment Terms: T/T, Western Union, D/A, D/P, L/C
    Supply Ability: 50000 Pieces/Per year
    Contact Now
    Detailed Product Description
    Type: Double Acting Work Medium: Hydraulic Oil
    Color: Customization Factory Visit: Available
    Body Material: According To User Requirements Sample: Available
    High Light:

    multi stage telescopic hydraulic cylinder

    ,

    high tonnage hydraulic cylinder

    Double Acting High Tonnage With Flange High Pressure Hydraulic Cylinder



    Products details:
    DALLAST high tonnage double acting hydraulic cylinders are designed specifically for heavy lifting up to 1,000 tons

    Integral stop ring provides piston blow-out protection
    Double-acting for positive retraction
    Baked enamel outside finish and plated pistons provide superior corrosion resistance
    Safety valve in retract side of cylinder helps to prevent damage in case of accidental over-pressurization
    Interchangeable, hardened grooved saddles are standard
    Plunger wiper reduces contamination, extending cylinder life



    Model

    Capacity

    (T)

    Working Pressure

    (MPa)

    Closed Height
    (mm)

    Outside Diameter

    (mm)

    Oil Capacity

    (cm³)

    KET-CLRG-502 50 70 166 130 385
    KET-CLRG-1002 100 70 664 165 664
    KET-CLRG-1502 150 70 993 205 993
    KET-CLRG-2002 200 70 1330 235 1330
    KET-CLRG-2502 250 70 1832 275 1832
    KET-CLRG-3002 300 70 2281 310 2281
    KET-CLRG-4002 400 70 2800 365 2800
    KET-CLRG-5002 500 70 3653 400 3653
    KET-CLRG-6002 600 70 4276 430 4276
    KET-CLRG-8002 800 70 5881 510 5881
    KET-CLRG-10002 1000 70 7392 560 7392



    The benefits of DALLAST



    1. There are over 120 kinds of hydraulic cylinder for you to choose, including cylinder used for coalmine machinery, tippers, engineering machinery and marine equipment. Every year many new products are developed to meet customer's diversified requirement.

    2. We own over 10 production line and 700 sets of prodution equipment to satisfy customer's large demand in short delivery time.

    3. Strict quality control and assurance system from raw material to finished products to guarantee high quality requirement.

    4. National and international standard recognition



    Exclusion clause:

    1. This warranty does not cover & DALLAST shall have no responsibility for:

    2. Troubleshooting, diagnostic, removal, or reinstallation labor charges;

    3. Freight charges for either defective parts or new or repaired parts unless prior written approval is obtained from DALLAST;

    4. Corrosion unless the material is found to be out of specification;

    5. Failure due to contamination introduced to the cylinder;

    6. Paint unless out of specification



    FAQ

    Q: How to make payment?
    A: Once order confirmed, we will prepare proforma invoice with our banking details.



    Q: How long does it take to process orders?
    A: It usually takes 15-20 business days to process most orders for no stock, if stock available, only take10-15business days.



    Q: What is the packing method?
    A: Carton or According to Customer's Require



    Q: How to ship?
    A: Sea freight



    Q: What is the warranty?
    A: 12 months against B/L date.



    Double Acting Flange High Pressure Hydraulic Cylinder High Tonnage
